Name: DIN-RAIL Unmanaged 2-Port 1000M Fx + 8-Port 1000M Tx Industrial Switch
Brand: Beijing Fibridge Co., Ltd.

DIN-RAIL Unmanaged 2-Port 1000M Fx + 8-Port 1000M Tx Industrial Switch

Fibridge F6-8GT2GX series network DIN-RAIL industrial switch is a high-performance ethernet access equipment developed by Beijing Fibridge. It has 8 10 / 100/1000 mbps Ethernet interfaces and 2 1000 mbps optical port. Built-in power module, the product provides 220V AC input or 12V DC input for options. The device operates at a temperature of -40℃～+85℃ Range and a humidity of %10~%90 (No condensation). The F6 series is compact desktop design, small size, light weight, easy to be placed in the desktop or cabinet. PoE+ function is optional.

Specification of DIN-RAIL Unmanaged 2-Port 1000M Fx + 8-Port 1000M Tx PoE Industrial Switch

Network Characteristics
Ethernet Protocol	Support IEEE802.3/802.3u/802.3x/802.3az
Flow Control	IEEE802.3x flow control
Network Interface	OPT: 1000MBase-FX Single/multimode SC/FC/SFP ETH: 10/100/1000MBase-T(X)Adaptive Ethernet RJ45 port
Network Interface
VLAN	No
MAC Addresses	4K
Huge Frame	Max size 9216
Cache	NO
Packet Buffer	20Gbps
Packet Forwarding Rate	14.48Mpps
Management	No
Optical Characteristics
Optical Interface	SC/FC/SFP(Optional)
Fiber Core Count	Single / Dual core transmission
Wavelength	1310nm/1550nm（850nm）
Fiber Mode	Single Mode / Multimode
Environmental Characteristics
Temperature & Humidity	Working temperature: -30℃～70℃ Storage temperature: -40℃～85℃ Working humidity: 10%～90% RH No condensation Storage humidity: 5%～90% RH No condensation



Power	AC 100-240V/50-60Hz Built-in switching power supply, DCDC48~56V 1.5A External power supply(PoE) DC12V 1A External power supply


MTBF	≥100000 hours

DIN-RAIL Unmanaged 2-Port 1000M Fx + 8-Port 1000M Tx PoE Industrial Switch

Support IEEE802.3/802.3u/802.3x/802.3az forward mode.
To meet the requirements of reliable work in harsh electrical environment.
Support for Port auto-negotiation.
Support flow control.
Support Poe+ function.
Industrial & Modular design make the equipment reliable and flexible.
Support overload protection.
Anti-link protection is supported.
Support light hot plug.
Level of protection: IP40.
ISO9000 quality system certified.
Pass the ministry of public security testing.
Obtain network qualification certificate.
